Testo 755-1 Current/voltage Tester
Exchangeable measuring tips.
Measuring current with a voltage tester? The innovative testo 755-1 makes this possible – and is therefore suitable for virtually all daily electrical measuring tasks. The practical automated switch-on function and automatic measurement parameter detection also mean you can work more reliably with it.
Instructions & Manuals
Testo 755-1 Current/voltage Tester - 0590 7551 Manuals
2 Years
The first voltage tester with current measurement is the testo 755-1. You can test electrical circuits or systems for voltage or de-energization, measure current or current consumption flow, and carry out continuity tests using a single instrument. In the process, the testo 755-1 voltage tester automatically detects and selects all the electrical parameters: you can start measuring without switching on or selection.
The measuring tips, which can be quickly exchanged, are also particularly user-friendly. This means you do not need to replace the whole instrument immediately in the event of damage. Just as practical: the integrated torch for illuminating dark measuring points.
The testo 755-1 current/voltage tester is a genuine allrounder that will make daily work easier.
Specifications
Easy, reliable operation through automatic measurement parameter detection
Suitable for almost all electrical measuring tasks
TECHNICAL DATA |
TESTO 755-1 |
TESTO 755-2
|
| Voltage measuring range | 6 to 600 V | 6 to 600 V |
| Current measuring range | 0.1 to 200 A AC | 0.1 to 200 A AC |
| Resistance measuring range | 1 Ω to 100 kΩ | 1 Ω to 100 kΩ |
| Continuity testing | < 50 Ω | < 50 Ω |
| Rotating magnetic field testing | - | > 100 to 690 V |
| Single pole phase testing | - | 100 to 690 V at 50/60 Hz |
| Display (counts) | 4,000 | 4,000 |
| Measuring point illumination | YES | YES |
| Overvoltage category | CAT4/600 V CAT3/1,000 V |
CAT4/600 V CAT3/1,000 V |
| Protection class | IP 64 | IP 64 |
| Operating temperature | -10 to +50°C | -10 to +50°C |
| Storage temperature | -15 to +60°C | -15 to +60°C |
| Dimensions (L x W x H) | 199 x 62 x 40 mm | 199 x 62 x 40 mm |
| Weight | 306 g | 306 g |
| Warranty | 2 years | 2 years |
| Authorizations | TÜV, CSA, CE | TÜV, CSA, CE |
| Standards | EN 61243-3:2010, EN 61010-1 |
EN 61243-3:2010, EN 61010-1 |
Testo 755-1 Current/voltage Tester
Well designed with a couple of extra features that the user may find very helpful.
